HFD-2000 Multi-channel Ultrasonic Flaw Detection Board with 0.001mm Display Accuracy and 0.2-30MHz Frequency Range

HFD-2000 Multi-channel Ultrasonic Flaw Detection Board with 0.001mm Display Accuracy and 0.2-30MHz Frequency Range
HFD-2000 Multi-channel Ultrasonic Flaw Detection Board with 0.001mm Display Accuracy and 0.2-30MHz Frequency Range HFD-2000 Multi-channel Ultrasonic Flaw Detection Board with 0.001mm Display Accuracy and 0.2-30MHz Frequency Range

Gambar besar :  HFD-2000 Multi-channel Ultrasonic Flaw Detection Board with 0.001mm Display Accuracy and 0.2-30MHz Frequency Range

Detail produk:
Tempat asal: Cina
Nama merek: HUATEC
Sertifikasi: ISO, CE, GOST
Nomor model: HFD-2000
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1 buah
Kontak

HFD-2000 Multi-channel Ultrasonic Flaw Detection Board with 0.001mm Display Accuracy and 0.2-30MHz Frequency Range

Deskripsi
Tampilkan akurasi: 0,001mm

HFD-2000 Multi-channel Ultrasonic Flaw Detection Board
The HFD-2000 ultrasonic automatic detection board enables rapid, non-destructive, and precise monitoring, localization, evaluation, and diagnosis of workpiece damage. This essential system in the non-destructive testing industry supports automatic inspection, C-scan imaging, online flaw detection, thickness measurement, and 24/7 ultrasonic signal monitoring across various industrial sectors.
Technical Specifications
Parameter Specification
Detection Range 0 to 15m
Gain Range 0 to 120dB
Sensitivity Margin >65dB
Dynamic Range 38dB
Resolution 42dB (5P14)
Speed of Sound Range 100 to 20,000m/s
Frequency Range 0.2 to 30MHz
Display Accuracy 0.001mm
Repeated Firing Frequency 16 to 25kHz
Vertical Linear Error <2%
Core Functions
24/7 monitoring with automatic detection, gain control, measurement, capture, alarm, storage, and report generation
Gigabit Ethernet transmission of waveform data, gate height data, alarm data, and control signals
Real-time upload of all 20K detection results
Scalable channel configuration: single board, 4 channels, 8 channels, or multi-board systems supporting hundreds of channels
Multiple communication interfaces: Gigabit Ethernet, RS-485, RS-232, and Bluetooth
IP67-rated dustproof and waterproof construction with optional long-term underwater detection capability
Standard PC software displaying real-time multi-channel A-scan waveforms and test results
Four optional gates for flexible testing configurations
Battery-powered operation or continuous plugged-in operation
Comprehensive inspection software with multi-channel A-scan, strip chart, C-scan functions, and defect management
Software development support with communication protocols and basic function libraries
Industry Applications
Widely utilized in power generation, petrochemical, boiler pressure vessel, structural steel, aerospace, railway transportation, automotive, machinery manufacturing, and various industrial fields requiring precision non-destructive testing.
