HDL-430D High Capacity NDT Film Processing Machine Auto Chemical Replenishment Roll & Flat X Ray Film Processor

HDL-430D High Capacity NDT Film Processing Machine Auto Chemical Replenishment Roll & Flat X Ray Film Processor
HDL-430D High Capacity NDT Film Processing Machine Auto Chemical Replenishment Roll & Flat X Ray Film Processor HDL-430D High Capacity NDT Film Processing Machine Auto Chemical Replenishment Roll & Flat X Ray Film Processor

Gambar besar :  HDL-430D High Capacity NDT Film Processing Machine Auto Chemical Replenishment Roll & Flat X Ray Film Processor

Detail produk:
Tempat asal: Cina
Nama merek: HUATEC
Sertifikasi: CE
Nomor model: HDL-430D
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1 set
Harga: USD8625-USD9750/SET
Kemasan rincian: Kemasan kotak kayu
Waktu pengiriman: 7-10 hari kerja setelah menerima pembayaran Anda
Syarat-syarat pembayaran: T/T, Western Union, PayPal
Menyediakan kemampuan: 10 set/bulan
Kontak

HDL-430D High Capacity NDT Film Processing Machine Auto Chemical Replenishment Roll & Flat X Ray Film Processor

Deskripsi
Ukuran Film: Minimum: 50×100mm, Max. Minimum: 50×100mm, Maks. Width: 450mm Lebar: 450mm Waktu pengerjaan: 3.2～16min. 3,2～16 menit. （0.1min. （0,1 menit. adjustable） dapa
Kecepatan Umpan Masuk: 155～765mm/menit. Volume tangki: Dev. Dev. Fix. Memperbaiki. Wash.13L for each Cuci.13L untuk m
Dev. Dev. Temp. Suhu.: 20～40℃ （0,1℃ dapat disesuaikan） Suhu Kering.: 20～70℃ （5℃ dapat disesuaikan）
Konsumsi Daya: 110～240V 10A, 50 atau 60Hz
Menyoroti:

NDT film processing machine auto chemical replenishment

,

high capacity X-ray film processor

,

flat X-ray film processor with warranty

HDL-430D High Capacity NDT Film Processing Machine Auto Chemical Replenishment Roll & Flat X Ray Film Processor


The machine is widely used in the quality inspection of boilers, shipbuilding, pressure vessels, oil and gas pipeline construction, aerospace and other equipment, and is widely praised by customers in the testing industry!


Specification

 Model: HDL-430D

Film Size: Minimum: 50×100mm, Max. Width: 450mm

Film Type: roll orflat film

Film probes: 4 sets of micro inductive probes

Processing Time: 3.2～16min. (0.1min. adjustable)

Feed-in Speed:155～765 mm/min.

Processing Capacity: 350×430mm 22-109 sheets/hr,80×300mm 110-545 sheets/hr (when 5.4 min processing time)

Tank Volume: Dev. Fix. Wash.13L for each

Supplementary: automatically replenish water according to film size,waterreplenishment 50～700ml/㎡

Dev. Temp.: 20～40℃ (0.1℃ adjustable)

Fix. Temp.:automatically adjustable

Dry Temp.: 20～70℃ (5℃ adjustable)

Water Temp.: 5～30℃

Washing Controlling: when working: automatic water intake less than2L/min, standby: automatic shutdown

Power Consumption:110～240V 10A, 50 or 60Hz

Weight: G.W: 128kg, N.W: 88kg

Dimension: appr.: 108×71.5×113cm3
